Black 16.6*13.5mm lED profile channel Surface Mounting Black Diffuse

Basic Information
Place of Origin: China
Brand Name: kc
Certification: Rohs
Model Number: KL2
Minimum Order Quantity: 100
Price: US 1-2 / pcs
Packaging Details: Inner Clear PE bag+EPE FOAM+Carton Box
Detail Information
Product Name: Aluminum Profil Type: KL1
Material: 6063 T5 Size: 16.5*13.5mm
Color: Black /Silver/White Treatment: Anodized
Cover: Clear/Semi-clear/Black Temper: T3-t8 Temper
Warranty: 3-5years Delivery: 15-21 Days
Waterproof: IP20
High Light:

16.6*13.5mm LED Profile Channel

,

AL6063 LED Profile Channel

,

16.6*13.5mm LED Profile Housing


Product Description

Black 16.6*13.5mm LED Profile Channel Surface Mounting Black Diffuse



KL2 Surfaced LED Strip Housing for LED Strip Anodized Aluminu with Black Cover Recessed Aluminum LED Profile

Application
- Kitchen cabinets LED Lighting

- Furniture LED Lighting
- Store shelf LED lighting
- Home using residential building decorations lighting

- Exhibition booth LED lighting

Assembly
- Mounted to the groove with appropriate mounting clips


Additional information
- The LED profile is suitable for bending into gentle arches, in the plane adjacent to the LED strip
- Can be equipped with transparent and frosted covers

- Space for LED strip up to 5mm width

Main Specifications



Model No.: KL2
Item Type: Surfaced Aluminum LED Profile
Dimensions: (W)16.5*(H)13.5mm
Standard length: 2m/pcs
Customized-length: Available on request
Suitable for led strip: PCB width up to 12.5mm
Material: 6063 T5 Aluminum Alloy
Treatment: Sandblasting oxidation
Finished color: Silver, black, white
Diffuser material: PMMA/PC
Diffuser finished: Opal/Frosted/Clear/ Black
Accessories: End caps, clips
Installation: Surface-mounted
Standard Package: Inner Clear PE bag+EPE FOAM+Carton Box
Customized Package: Available on request
Handling time Samples within 3 working days
Batch order 3-15 working days upon stocks
Shipment By sea, by air, by express for option


Drawing:
Black 16.6*13.5mm lED profile channel Surface Mounting Black Diffuse 0
Application

Black 16.6*13.5mm lED profile channel Surface Mounting Black Diffuse 1

FAQ:

Q: Are you a factory or trading company?
A: We're a self -own factory, and can provide a one-stop service for all of our customers, from material to various surface treatments, from technical sales to shipping and after-sales. So as to save the cost for clients, control the quality and lead time, provide the best services.


Q: Do you accept OEM and ODM?
A: Yes, we have our own mold shop and rich experience in OEM and ODM services.


Q: How much the mold cost?
A: The mold cost depends on different designs, we’ll evaluate per your drawing.

Q: Can print LOGO on led profiles or OEM Packing?
A: Yes, could laser print on led profile/PC Cover. customized packing is available based on order quantity.


Q: What is your delivery time?
A: Most products have stocks. Samples within 3 working days, batch order 3-15 working days upon stocks.


Q: How do you ship the goods and how long?
A: Usually by international express delivery such as DHL, UPS, FedEx, TNT (3-7 working days), by air or by s
